دست فنر چرخ جلو Toyota Land Cruiser
OEM Code : 48210-60380, 48110-60160, 48110-60220, 48110-60410, 48110-60411, 48210-60650, 48110-60170, 48210-60410
Product Introduction
Front: Toyota Land Cruiser 60 Series 4door (1980-1990); Toyota Samurai (Venezuela); BJ60series, FJ60series
Reference OEM# (90-112)/ 48110-60170/ 48210-60410/ 48210-60380/ 48210-60410/ 48210-60380/ 48210-60650/ 48110-60160/ 48110-60170/ 48110-60220/48110-60170/ 48110-60410/ 48110-60411
Special properties
Technical Specifications
| Vehicle Type | |
|---|---|
| Installation Location | |
| OEM Code | 48110-60160, 48110-60170, 48110-60220, 48110-60410, 48110-60411, 48210-60380, 48210-60410, 48210-60650 |
| After Market Code | 90-112 |
| Leaf Spring Width | |
| Leaf Spring Thickness | |
| Number of Main Layers (M) Leaf Spring | |
| Short edge length - Leaf Spring | |
| Long edge length - Leaf Spring | |
| Eye diameter (Short edge - Leaf spring) | |
| Eye diameter (Long edge - Leaf spring) | |
| Leaf Spring Free Arch | 170 |
| Name of car/ cabin/ trilly | FJ60series, Toyota Land Cruiser 60 Series 4door (1980-1990); Toyota Samurai (Venezuela); BJ60series |
